Specifications |
||
|
Function |
2GA |
|
|
Test Materials |
Wood and Building Materials |
|
|
Moisture Content Range |
Material 1 8.8~54.8% Beech, Spruce, Larch, Birch, Cherry, Walnut |
|
|
Material 2 7.0~47.9% Oak, Pine, Maple, Ash Tree, Douglas Fir, Meranti |
||
|
Material 3 0.9~22.1% Cement, Concrete Plane, Plaster Produce |
||
|
Material 4 0.0~11.0% Anhydrite Plane |
||
|
Material 5 0.7~8.6% Cement Mortar |
||
|
Material 6 0.6~ 8.6% Lime Mortar, gypsum |
||
|
Material 7 0.1~16.5% Brick |
||
|
Resolution |
0.1%, 1℃ |
|
|
Accuracy |
±1%, ±1.5℃ |
|
|
Sampling Time |
0.5s |
|
|
Features |
|
|
Model |
2GA |
|
Auto zero |
√ |
|
Environment temperature display |
√ |
|
℃/℉ |
√ |
|
Green/Yellow/Red LED indication |
√ |
|
Display |
5 digits with backlight |
|
Protection class |
IP 20 |
|
Testing depth |
11mm |
|
Operation Temperature |
(-10~+50) ℃ |
|
Storage Temperature |
(-40~+70) ℃ |
|
General Information |
|
|
Model |
2GA |
|
Power Supply |
9V 6F22 |
|
Product Size |
130×50×20mm |
|
Product Weight |
100g |
|
Standard Accessories |
Battery / instruction manual |
2GA User's Manual
