True RMS (TRMS) – Provides precise readings on non-sinusoidal waveforms for industrial and electronic applications.
-
5999 Counts Display – Higher resolution than standard 3½-bit meters for more detailed measurements.
-
NCV (Non-Contact Voltage) – Safely detects live wires without physical contact.
-
REL Mode – Sets a reference value for relative measurements or zeroing test lead resistance.
-
Backlight & Flashlight – Built-in backlight for dim environments, plus a flashlight for illuminating dark work areas.
-
Comprehensive Functions – Supports capacitance, frequency, hFE transistor test, diode test, and continuity buzzer for all-in-one troubleshooting.
-
Data Hold – Freezes readings for easy recording.
-
Auto Power-Off & Low Battery Indication – Extends battery life and alerts users when power is low.
-
Overload Prompt – Warns when input exceeds the range to prevent damage.
|
Specifications |
||
|
Function |
Range |
ACCURACY |
|
DCV |
40mV/400mV/4V/40V/400V/1000V |
±(0.5%+4) |
|
ACV |
40mV/400mV/4V/40V/400V/750V |
±(0.8%+10) |
|
DCA |
400uA/4000uA/40mA/400mA/4A/10A |
±(1.2%+8) |
|
ACA |
400uA/4000uA/40mA/400mA/4A/10A |
±(1.5%+10) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(0.8%+4) |
|
Capacitance |
6nF/60nF/600nF/6uF/60uF/600uF/6mF/60mF/100mF |
±(3.5%+20) |
|
Frequency |
10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/20MHz |
±(0.5%+10) |
|
Temperature |
(-20～1000)℃/(-4～1832)℉ |
±(1.0%+5) |
|
Features |
|
|
Model |
97 |
|
Diode and continuity |
√ |
|
Triode test |
√ |
|
Auto / manual range convertible |
√ |
|
Data hold |
√ |
|
Flashlight |
√ |
|
NCV (Non-contact voltage test) |
√ |
|
Relative / duty cycle measurement |
√ |
|
Low battery indication |
√ |
|
Backlit display |
√ |
|
Auto power off |
√ |
|
True RMS |
√ |
|
Sampling rate |
3 times/s |
|
AC Frequency response |
(40-1000) Hz |
|
Max. Display |
3999 |
|
Input resistance |
10MΩ |
|
General Information |
|
|
Model |
97 |
|
Power supply |
AAA,1.5V*4 |
|
Product weight |
395g |
|
Product size |
186mm×92mm×52mm |
|
Standard accessories |
Temperature probe, multi-function socket, test leads, battery, manual |
