Specifications |
|||
|
Function |
Range |
6412 |
6412+ |
|
Resistance range |
0.010Ω~0.099Ω |
±1.0%+0.01 |
±1.0%+0.01 |
|
0.10Ω~0.99Ω |
±1.0%+0.01 |
±1.0%+0.01 | |
|
1.0Ω~49.9Ω |
±1.5%+0.1 |
±1.5%+0.1 |
|
|
50.0Ω~99.5Ω |
±2.0%+0.5 |
±2.0%+0.5 |
|
|
100Ω~199Ω |
±3.0%+1 |
±3.0%+1 |
|
|
200Ω~395Ω |
±6.0%+5 |
±6.0%+5 |
|
|
400Ω~590Ω |
±10.0%+10 |
±10.0%+10 |
|
|
600Ω~1000Ω |
±20.0%+20 |
±20.0%+20 |
|
|
AC current range |
0-80mA |
±2.5%+1 |
--- |
|
80mA-650mA |
±2.5%+2 |
||
|
650mA-4A |
±2.5%+10 |
||
|
4A-30A |
±2.5%+20 |
||
|
Single measurement time |
1s |
1s |
|
|
Current measure frequency |
50/60Hz Auto |
--- |
|
|
Range for alarm of current |
1 -499mA |
--- |
|
|
Range for alarm of resistance |
1 -199Ω |
||
|
Features |
||
|
Model |
6412 |
6412+ |
|
Functions |
Ground Resistance |
Ground Resistance |
|
Alarm beeping |
√ |
√ |
|
Date hold |
√ |
√ |
|
Overflow indication |
√ |
√ |
|
Auto power off |
√ |
√ |
|
Double insulation |
√ |
√ |
|
Range |
Auto range |
Auto range |
|
Data storage |
99 groups |
99 groups |
|
Interference indication |
Beeps / NOISE symbol blinking |
|
|
Clamp size |
65mmx32mm |
|
|
LCD Size |
47*28.5mm / 4 digits |
|
|
Working Condition |
(-10～40)℃; <80%Rh |
|
|
General Information |
||
|
Model |
6412 |
6412 |
|
Power supply |
1.5V AAA*4, DC 6V power adapter |
|
|
Product color |
Black + orange |
|
|
Product size |
258mm X 85mm X 58mm |
|
|
Product weight |
1800g |
|
|
Standard accessories |
Verification resistor, batteries, manual, tool case |
|
