Description

The instrument can quickly, simply, accurately and reliably judge the no-load energy, the on-load condition, the internal resistance of the battery and the charging system conditions of 6V and 12V lead-acid accumulator. The instrument, provided with 32-bit high-end micro control unit for computation operation, can automatically judge the batteries with different voltages (6V or 12V) at the same time and the charging state thereof. Moreover, the instrument is internally provided with reverse polarity protection, over voltage input protection, poor contact prompt and over-temperature prompt. Therefore, the test can be smoothly, simply and conveniently carried out. The on-load test method recommended by the international battery association is adopted for the instrument. Specifically, the corresponding mode is selected and set in advance according to the rated capacity of the accumulator tested thereby, and the short-time heavy load discharge of the battery is controlled to detect the discharge conditions of the batteries at the same time, and three LED indicator lights are adopted to simply and conveniently display the test result. The test process of the instrument and the data result judgment are processed by the internal arithmetic unit. Additionally, the test result can be reviewed.

The instrument shell is made of solid ABS engineering materials, and the load heating simulation part is up and down installed with stainless steel porous plate, and the fan is configured to strengthen heat dissipation in order to make the test process more stable and more reliable. The test line part is composed of thick pure copper test wire, and is also configured with four-wire Kelvin test clamp for connection. The test sampling data are directly sampled from the outgoing terminal of the battery in order to really recover the battery aworking condition in the battery working process and make the test result more accurate. Excellent materials, reliable process and design, advanced circuit control, good workmanship and quality control system can ensure the high quality, accuracy and reliability of the instrument.

Specifications

Specifications
Model	3015A	3015B	3015C (3 in 1Type)
Battery Type	6V / 12V (lead-acid storage battery)	6V / 12V (lead-acid storage battery)	Power Battery	Starter Battery
Battery Type	6V / 12V (lead-acid storage battery)	6V / 12V (lead-acid storage battery)	6V/12V	12V
Load Test Current	About 20 A	About 80A	About 80A
Max. Voltage	DC 19.99V	DC 19.99V	DC 19.99V
CCA(Cold Cranking Amps)	---	---	100~1700
IEC	---	---	100~1000
EN	---	---	100~1700
DIN	---	---	100~1000
Working Voltage	9V ~ 18V	9V ~ 18V	9V ~ 18V
Internal Resistance	1.00~99.99mΩ	1.00~99.99mΩ	1.00~99.99mΩ
Battery Capacitance	5AH-80AH	40AH-200AH	40AH-200AH
Engine system activation load test	---	---	√
Maximum load system test	---	---	√
Charging system test	√	√	√

Features
Model	3015A	3015B	3015C
LED indication for battery condition & charging system	√	√	---
LCD digital display	---	---	√
Overvoltage protection	√	√	√
Polarity re verse protection	√	√	√

General Information
Model	3015A/3015B	3015C
Product size	115mm70mm205mm	115mm70mm205mm
Product weight	860g	900g
Standard accessories	Manual	Manual
