Features
Auto and Manual Range with Hold Function,55000 Counts
AC true RMS measurement, measurement bandwidth: 8246B:20Hz ~ 1KHz;8246A: 20Hz~50KHz
Decibel measurement with reference impedance of 1 to 2400 Ω
Measure DC and AC Current, Measure DC and AC Voltage
Measure Four-wire and Two-wire Resistance
Measure Capacitance 110MF
Diode, Duty Cycle, Buzzer and Frequency
Thermocouple measurement:
K-Type, high-precision temperature sensor, automatic cold junction compensation, temperature display at °C or °F
Data hold, Auto Power Off (settable), Display the unit
Max./Min./Avg Value and REL Value
Measuring display Rate: fast 20 times / sec, slow 5 times / sec
Dual Over Load Protection, PC Communication Supported
The multimeter data recording function can perform data recording of large capacity and multiple data parameters, and can read and data the recorded data in the computer. Data records can be configured: record start delay / record interval / number of records.
|
Specifications |
|||||
|
Function |
Range |
8246A |
8246B |
||
|
DC V |
50mV/500mV/5V/50V/500V/1000V |
±(0.025%+5) |
±(0.025%+5) |
||
|
AC V |
50mV/500mV/5V/50V/500V/1000V |
±(0.5%+30) |
±(0.5%+30) |
||
|
DC A |
500uA/5000uA/50mA/500mA/5A/10A |
±(0.15%+20) |
±(0.15%+20) |
||
|
AC A |
500uA/5000uA/50mA/500mA/5A/10A |
±(0.5%+30) |
±(0.5%+30) |
||
|
OHM |
500Ω/5KΩ/50KΩ/500KΩ/5MΩ/50MΩ |
±(0.05%+10) |
±(0.05%+10) |
||
|
CAP |
10nF/100nF/1000nF/10µF/100µF/1000µF/10mF/100mF |
±(5%+5) |
±(5%+5) |
||
|
Frequency |
10Hz/100Hz/1000Hz/10kHz/100kHz |
±(0.02%+4) |
±(0.02%+4) |
||
|
Thermocouple K |
(-200.0°C～1372.0)℃/(-328.0°F～2501.6)℉ |
±(0.5%+0.5) |
±(0.5%+0.5) |
||
|
RTD Pt100 |
(-200.0°C～800.0)℃/(-328.0°F～1472.0)℉ |
±(0.5%+0.5) |
±(0.5%+0.5) |
||
|
Features |
|||
|
Model |
8246A |
8246B |
|
|
Bandwidth |
√ |
√ |
|
|
Diode & continuity test |
√ |
√ |
|
|
2 /4 wire resistance measurement |
√ |
√ |
|
|
MAX/MIN/relative value |
√ |
√ |
|
|
Display type |
√ |
√ |
|
|
Display hold |
√ |
√ |
|
|
SCPI |
√ |
√ |
|
|
dBm |
√ |
√ |
|
|
Duty Cycle |
√ |
√ |
|
|
Thermocouple k & RTD PT100 measurement |
√ |
√ |
|
|
Data recording |
50000 group |
50000 group |
|
|
Display rate |
Fast / slow |
Fast / slow |
|
|
Operation Way |
Auto/Manual |
Auto/Manual |
|
|
Interface |
RS-232, USB |
RS-232, USB |
|
|
Max. Display |
55000 |
55000 |
|
|
General Information |
||
|
Model |
8246A |
8246B |
|
Power supply |
250V±10%AC |
|
|
Product color |
White + grey |
|
|
Product weight |
2000g |
|
|
Product size |
245 × 220 × 82mm |
|
|
Standard accessories |
Manual, power cable, testing leads, USB cable, DB/9 cable, software CD |
|
